☑Accommodates NE8MC* or any standard RJ45 plug
☑NE8FF coupler (adapter) for cable to cable mating – use with NE8MC carriers or any standard RJ45 plug
☑Approved latch lock system
Éntreme en contacto con gratis las muestras y los vales.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
Si usted tiene alguna preocupación, proporcionamos ayuda en línea de 24 horas.
x| Género | Femenino | Tipo | Adaptador |
|---|---|---|---|
| Electrónica industrial | Accesorios | ||
| Resaltar | Plug Signal Adapter Cable Connectors,Wholesale Signal Adapter Cable Connectors |
||
Connection Type | Coupler (adapter) |
Gender | Female |
Contact resistance | < 10 mΩ |
Dielectric strength | 1 kVdc |
Frequency Range | 1 - 100 MHz |
Insulation resistance | > 0.5 GΩ |
Rated current per contact | 1,5 A |
Rated voltage | < 50 V |
Standards compliant | TIA/EIA 586B, IEC11801 |
Insertion force | ≤ 20 N |
Pull out force | ≤ 20 N |
Service life | > 1000 mating cycles |
Locking device | Latch lock |
Contacts | Bronze (CuSn8) |
Contact plating | 0.2 µm Au over Ni plating |
Inner core | PBTP 15 % GR |
Shell | AlMgSi 0.5, black plated |
Clamping sleeve | CuZn35Pb2, tinned |
Flammability | UL 94 HB |
Temperature range | -30 °C to +80 °C |
